Schneider Electric BMXXBP1200 Modicon X80 12-Slot X-Bus Backplane

Schneider Electric BMXXBP1200 Modicon X80 12-Slot X-Bus Backplane

Product Overview

The Schneider Electric Schneider Electric BMXXBP1200 is a 12-slot high-density X-Bus backplane for the Modicon X80 platform. It provides the mechanical and electrical foundation for M340 and M580...

20 people are viewing this right now

Availability: Low stock: 94 left

SKU: BMXXBP1200
Vendor: Schneider
Category: 2-Slot X-Bus Backplane
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Product Overview

The Schneider Electric Schneider Electric BMXXBP1200 is a 12-slot high-density X-Bus backplane for the Modicon X80 platform. It provides the mechanical and electrical foundation for M340 and M580 PLC systems, enabling communication and power distribution between CPU, power supply, and I/O modules. We supply this unit as 100% Brand New original equipment.

Technical Specifications

Parameter Specification
Compatible Platforms Modicon M340 / M580
Total Slots 12 slots
Bus Type X-Bus
Power Supply Slot 1 dedicated slot
Module Slots 11 slots
Mounting Type DIN rail or panel mount
Dimensions 503.2 × 103.7 mm
Current Consumption 340 mA (3.3V), 164 mA (24V)
MTBF > 1,700,000 hours

Engineering Advantages

High-Density Integration

Supports up to 12 modules in a single rack, reducing cabinet space and wiring complexity.

Platform Flexibility

Compatible with both M340 and M580 systems, enabling smooth CPU upgrades without rewiring I/O.

Mechanical Stability

Reinforced structure ensures reliable module alignment under vibration and industrial stress.

Stable Power Distribution

Optimized internal bus design ensures consistent voltage delivery across all installed modules.

FAQs

Can Ethernet (BME) modules be used?

No, this is an X-Bus backplane. Ethernet backplane (BME) modules require BMEX series racks.

Are blanking plates required?

Yes, unused slots should be covered with BMXXCA1001 or BMXXCA1002 to maintain protection and IP rating.

Is there a power limit?

Yes, total power depends on the installed power supply module and must be calculated per system requirements.
