The Schneider Electric CAD32MD is a robust TeSys D control relay engineered for the reliable switching of electromagnetic loads, including AC-15 and DC-13 applications. This 5-pole control relay features a 220 V DC standard coil and provides a versatile contact configuration of 3 Normally Open (NO) and 2 Normally Closed (NC) contacts. Designed for high-performance industrial environments, it supports operating rates of up to 180 cycles per minute.

Features

• TeSys D control relay with 5-pole contact arrangement (3NO + 2NC).
• Equipped with a 220 V DC standard coil and integrated surge suppression.
• Compact 45 mm width suitable for space-constrained control panels.
• IP2X front face protection conforming to VDE 0106.
• Rated for high-frequency operation up to 180 cycles/min.
• Screw clamp terminal connections for secure wiring.

Applications

• Industrial automation systems and PLC interfacing.
• Control circuits for HVAC equipment and building management systems.
• Switching of auxiliary relay loads and larger contactor coils.
• General signaling and control logic in industrial infrastructure.

Technical Specifications

Installation Guidelines

• Mounting: Designed for clipping onto 35 mm DIN rails or direct screw mounting.
• Wiring: Use screw clamp terminals with a tightening torque of 1.7 N·m.
• Cable Capacity: Supports 1 or 2 cables, 1–4 mm² (flexible or solid).
• Environment: Suitable for ambient temperatures between -40 degC and +60 degC.
• Safety: Ensure power is disconnected before installation or maintenance.

FAQ

What is the CAD32MD?

The CAD32MD is a TeSys D control relay from Schneider Electric, designed for industrial control and switching applications.

What is the contact configuration?

The unit features 5 contacts total, consisting of 3 Normally Open (NO) and 2 Normally Closed (NC) poles.

What is the required tightening torque for the terminals?

The terminals should be tightened to 1.7 N·m using a Philips No. 2 or 6 mm flat-head screwdriver.
