Schneider Electric DEA 106 Analog Input Module

Schneider Electric DEA 106 Analog Input Module

Description

The Schneider Electric DEA 106 is a high-performance analog input module engineered for precise signal acquisition in industrial automation environments. Designed for compatibility with TSX and Modicon PLC platforms, this...

22 people are viewing this right now

Availability: Low stock: 5 left

SKU: DEA 106
Vendor: Schneider
Category: Analog Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Schneider Electric DEA 106 is a high-performance analog input module engineered for precise signal acquisition in industrial automation environments. Designed for compatibility with TSX and Modicon PLC platforms, this module provides reliable signal conditioning and data conversion for critical process variables. Its robust design ensures consistent operation in demanding control applications.

Features

  • Six isolated input channels for enhanced signal integrity and noise immunity.
  • Configurable input ranges supporting both 0-10V voltage and 4-20 mA current signals.
  • High-precision 12-bit resolution for accurate process monitoring.
  • Fast conversion time of 2.5 ms per channel to support dynamic control loops.
  • Galvanic isolation of 1500V between the input channels and the backplane.

Technical Specifications

Manufacturer Schneider Electric
Model DEA 106
Type Analog Input Module
Number of Channels 6 (Isolated)
Input Ranges 0-10V, 4-20 mA
Resolution 12 Bits
Conversion Time 2.5 ms per channel
Isolation 1500V (Channel to Backplane)
Weight 0.28 kg

Installation Guidelines

  • Ensure the PLC rack power is disconnected before installing or removing the module.
  • Mount the module securely in the designated rack slot to ensure proper backplane connection.
  • Use shielded twisted-pair cabling for analog signal inputs to minimize electromagnetic interference (EMI).
  • Maintain proper spacing within the cabinet to allow for adequate ventilation and heat dissipation.
  • Verify that all signal wiring is correctly terminated and that input ranges are configured according to the specific application requirements.

FAQ

What is the primary function of the DEA 106 module?

The DEA 106 is an analog input module used to convert external voltage or current signals from field sensors into digital data for processing by Schneider Electric PLC systems.

Does this module require external power for the inputs?

The DEA 106 is designed to interface with standard 0-10V and 4-20 mA signals. Please refer to your specific system wiring diagram to determine if your field devices require a separate loop power supply.

Is the DEA 106 compatible with all Modicon platforms?

The DEA 106 is specifically designed for integration with compatible TSX and Modicon PLC platforms. Always verify your specific CPU and rack compatibility before installation.
