Schneider Electric TSXP57024M Modicon Premium 32-Channel 24 VDC I/O Module

Schneider Electric TSXP57024M Modicon Premium 32-Channel 24 VDC I/O Module

Description

The Schneider Electric TSXP57024M is a high-density digital I/O module designed for the Modicon Premium automation platform. This module provides 32 channels of 24 VDC logic, facilitating robust signal processing...

25 people are viewing this right now

Availability: Low stock: 6 left

SKU: TSXP57024M
Vendor: Schneider Electric
Category: Digital I/O Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Schneider Electric TSXP57024M is a high-density digital I/O module designed for the Modicon Premium automation platform. This module provides 32 channels of 24 VDC logic, facilitating robust signal processing and interface capabilities for industrial control systems. Engineered for reliability in demanding environments, it ensures efficient data exchange between field devices and the PLC backplane.

Features

  • 32-channel digital I/O configuration for high-density applications.
  • Nominal operating voltage of 24 VDC with a stable range of 19.2 to 30 VDC.
  • Field-to-logic isolation rated at 1500 VAC to protect internal circuitry from field-side electrical surges.
  • Optimized power consumption with 120 mA typical draw from the 5 VDC backplane.
  • Compact design suitable for standard Modicon Premium rack mounting.

Technical Specifications

Product Model TSXP57024M
I/O Type 32-channel Digital Logic
Nominal Voltage 24 VDC
Operating Range 19.2 to 30 VDC
Isolation 1500 VAC (Field-to-Logic)
Backplane Current 120 mA @ 5 VDC
Max Field Power ~224 mA @ 24 VDC
Tariff Code 8537101190

Installation Guidelines

  • Ensure the PLC rack is powered down before installing or removing the module to prevent electrical damage or system faults.
  • Verify that the module is correctly seated in the backplane slot and secured using the integrated locking mechanisms.
  • Use appropriate shielded cabling for field I/O connections to minimize electromagnetic interference (EMI).
  • Maintain proper ventilation within the control cabinet to ensure the module operates within its specified temperature range.
  • Follow standard ESD (Electrostatic Discharge) precautions when handling the module to protect sensitive electronic components.

FAQ

What is the primary function of the TSXP57024M?
This module serves as a 32-channel digital I/O interface for the Schneider Electric Modicon Premium PLC series, allowing for the connection of 24 VDC field devices.

What is the isolation rating for this module?
The module provides 1500 VAC field-to-logic isolation, ensuring robust protection between the field wiring and the PLC processor.
