Schneider Electric TSXAEY800 Modicon Premium Analog Input Module

Schneider Electric TSXAEY800 Modicon Premium Analog Input Module

Product Overview

The TSXAEY800 is a high-density analog input module for the Schneider Electric Modicon Premium automation platform. It supports 8 high-level analog input channels and converts voltage or current...

27 people are viewing this right now

Availability: Low stock: 94 left

SKU: TSXAEY800
Vendor: Schneider
Category: Analog Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Product Overview

The TSXAEY800 is a high-density analog input module for the Schneider Electric Modicon Premium automation platform. It supports 8 high-level analog input channels and converts voltage or current signals into accurate 12-bit digital data for industrial monitoring and control. We supply this module as 100% Brand New and Original for reliable long-term operation.

Technical Specifications

Specification Details
Manufacturer Schneider Electric
Product Line Modicon Premium
Model Number TSXAEY800
Analog Input Channels 8
Input Level High Level
A/D Conversion 12 bits
Nominal Read Cycle Time 27 ms
Fast Read Cycle Time 3 ms + 3 ms per used channel
Isolation 1000 Vrms (Channels to Bus/Ground)
Electrical Connection 1 SUB-D 25-pin connector
Current Consumption 270 mA at 5 V DC
Input Overvoltage Protection Up to ±30 V
Net Weight 0.31 kg

Engineering Advantages

Fast Signal Processing

Fast read mode supports rapid data updates for real-time monitoring applications.

Strong Electrical Isolation

1000 Vrms isolation protects the PLC and improves system stability.

Built-In Protection

Overvoltage protection up to ±30 V helps prevent damage from wiring errors.

Compact Connectivity

The SUB-D 25-pin connector simplifies wiring and saves cabinet space.

Low Power Consumption

Efficient 270 mA current draw reduces load on the system power supply.

FAQs

What signal types does the TSXAEY800 support?

It supports configurable high-level voltage and current analog signals.

Is the module supplied in original packaging?

Yes, we provide the TSXAEY800 as 100% Brand New and Original in factory-sealed packaging.

What is the advantage of the fast read cycle?

It enables quicker signal updates for high-speed control and monitoring applications.

What does the 12-bit resolution provide?

The 12-bit conversion delivers 4,096 measurement steps for accurate analog signal processing.
