Schneider TSXDSZ08T2 Relay Discrete Output Module

Schneider TSXDSZ08T2 Relay Discrete Output Module

Description

The Schneider TSXDSZ08T2 is a high-performance relay discrete output module designed for integration within industrial automation systems. This module provides eight independent, isolated relay output channels, offering robust switching capabilities...

16 people are viewing this right now

Availability: Low stock: 1 left

SKU: TSXDSZ08T2
Vendor: Schneider
Category: Relay Output Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Schneider TSXDSZ08T2 is a high-performance relay discrete output module designed for integration within industrial automation systems. This module provides eight independent, isolated relay output channels, offering robust switching capabilities for various field devices. It is engineered for compatibility with the RMS-TSG-TZ-C series PLC architecture, ensuring seamless communication and reliable control in demanding industrial environments.

Features

  • Equipped with 8 discrete relay output channels for versatile control of field actuators and signaling devices.
  • Optimized for 24 VDC operation, supporting standard industrial control voltage requirements.
  • Compact, modular form factor designed for efficient space utilization within control panels and standard PLC racks.
  • IP20-rated enclosure provides protection against solid objects, ensuring operational safety.
  • Engineered for high reliability and consistent performance in automated control loops.

Technical Specifications

Manufacturer Schneider Electric
Model TSXDSZ08T2
Series RMS-TSG-TZ-C
Number of Channels 8
Output Type Relay
Voltage Rating 24 VDC
Load Current per Point 0.25 A
Response Time 10 ms typical
Operating Temperature 0 degC to 60 degC
Mounting Type DIN rail / PLC slot

Installation Guidelines

  • Ensure the PLC system is powered down before inserting or removing the module to prevent electrical damage or unintended operations.
  • Mount the module securely on a standard DIN rail or within the designated PLC rack slot, ensuring proper alignment with the backplane connector.
  • Use shielded cabling for output connections to minimize electromagnetic interference (EMI) in high-noise industrial environments.
  • Maintain adequate clearance around the module to facilitate proper airflow and cooling, adhering to the specified operating temperature range.
  • Verify that all field wiring is properly terminated and that the load current does not exceed the 0.25 A per-point rating.

FAQ

What is the primary function of the TSXDSZ08T2 module?

The TSXDSZ08T2 is a relay output module used to interface a PLC with external field devices, providing eight isolated channels for discrete switching control.

Is this module compatible with other Schneider series?

This module is specifically designed for use with the RMS-TSG-TZ-C series. Please verify your specific PLC rack configuration before installation.

What is the maximum current capacity per output?

Each of the eight relay output channels is rated for a maximum load current of 0.25 A.
