Schneider TSXSAY100 Modicon TSX BUS Coupler Module

Schneider TSXSAY100 Modicon TSX BUS Coupler Module

Description

The Schneider TSXSAY100 is a high-performance BUS Coupler Module belonging to the Modicon TSX series. This module is engineered to facilitate reliable communication between industrial control systems and various field...

27 people are viewing this right now

Availability: Low stock: 6 left

SKU: TSXSAY100
Vendor: Schneider
Category: BUS Coupler Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Schneider TSXSAY100 is a high-performance BUS Coupler Module belonging to the Modicon TSX series. This module is engineered to facilitate reliable communication between industrial control systems and various field devices. It acts as a critical interface component, ensuring seamless data exchange and synchronization across complex automation architectures.

Features

  • Reliable Data Transfer: Provides stable and consistent communication for demanding industrial integration tasks.
  • Protocol Versatility: Supports multiple industrial protocols, including Profibus DP, Modbus, and CANopen, for broad system compatibility.
  • High-Speed Communication: Optimized for fast data transfer rates to support real-time, low-latency control applications.
  • Compact Form Factor: Designed for space-efficient installation within standard control cabinets and system racks.
  • Rugged Construction: Built to operate reliably in harsh industrial environments with a wide operating temperature range.

Technical Specifications

Manufacturer Schneider Electric
Model TSXSAY100
Product Series Modicon TSX
Number of Ports 1
Supported Protocols Profibus DP, Modbus, CANopen
Interface Type Ethernet, RS232, RS485
Power Supply 24V DC
Operating Temperature -10 degC to 60 degC
Storage Temperature -40 degC to 85 degC
Mounting Type DIN Rail Mount
Weight 0.4 kg

Installation Guidelines

  • Mounting: Designed for standard DIN rail mounting. Ensure the module is securely snapped into place to prevent vibration-related disconnections.
  • Power Supply: Verify that the input power is a stable 24V DC source before connecting. Ensure correct polarity to avoid damage to internal circuitry.
  • Grounding: Follow standard industrial grounding practices for the DIN rail and the cabinet to minimize EMI interference.
  • Handling: Observe ESD (Electrostatic Discharge) precautions when handling the module. Avoid touching the connector pins or internal components.
  • Environment: Ensure adequate ventilation around the module to maintain operating temperatures within the specified -10 degC to 60 degC range.

FAQ

What is the primary function of the TSXSAY100?

The TSXSAY100 serves as a BUS coupler module within the Modicon TSX series, enabling communication between the controller and various field devices using protocols like Modbus, Profibus DP, or CANopen.

Can this module be used in high-temperature environments?

The module is rated for an operating temperature range of -10 degC to 60 degC. Please ensure your cabinet cooling systems maintain the ambient temperature within these limits for optimal performance.
