Schneider TSXTLYEX Modicon Premium PLC Bus Terminator

Schneider TSXTLYEX Modicon Premium PLC Bus Terminator

Description

The Schneider TSXTLYEX is a dedicated line terminator designed for the Modicon Premium automation platform. This component is essential for maintaining signal integrity at the end of the rack bus,...

15 people are viewing this right now

Availability: Low stock: 4 left

SKU: TSXTLYEX
Vendor: Schneider
Category: PLC Accessories
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Schneider TSXTLYEX is a dedicated line terminator designed for the Modicon Premium automation platform. This component is essential for maintaining signal integrity at the end of the rack bus, ensuring a stable and reliable communication environment for the system. The unit is supplied as a set of two connectors, specifically configured for rack-end termination.

Features

  • Designed for use with Modicon Premium TSXRKY..EX rack units.
  • Ensures proper bus termination to prevent signal reflection.
  • Includes two SUB-D 9 connectors, clearly labeled A and B for correct installation.
  • Compact and lightweight design for easy integration into existing rack configurations.

Technical Specifications

Specification Description
Part Number TSXTLYEX
Manufacturer Schneider Electric
Family Modicon Premium
Accessory Type Line Terminator
Destination Rack End
Kit Composition 1 x SUB-D 9 (Label A), 1 x SUB-D 9 (Label B)
Quantity Per Set 2
Compatibility TSXRKY..EX
Net Weight 0.05 kg

Installation Guidelines

  • Ensure the PLC system power is disconnected before installing or removing bus terminators to prevent electrical damage.
  • Verify that the rack is a compatible TSXRKY..EX model before attempting installation.
  • Insert the connectors into the designated rack-end ports, ensuring the A and B labels match the corresponding system requirements.
  • Handle with care to avoid bending the pins on the SUB-D 9 connectors.
  • Maintain a clean, dry environment free from excessive vibration or extreme temperatures to ensure long-term reliability.

FAQ

What is the primary function of the TSXTLYEX?

The TSXTLYEX acts as a line terminator for the Modicon Premium rack bus. It is required at the end of the bus to prevent signal reflections, which can cause communication errors or system instability.

What is included in the package?

The package contains a set of two SUB-D 9 connectors, one labeled A and one labeled B, specifically designed for the TSXRKY..EX rack series.
