Siemens 6ES7315-2EH13-0AB0 SIMATIC S7-300 CPU 315-2 PN/DP

Siemens 6ES7315-2EH13-0AB0 SIMATIC S7-300 CPU 315-2 PN/DP

Description

The Siemens 6ES7315-2EH13-0AB0 is a high-performance Central Processing Unit (CPU) designed for the SIMATIC S7-300 automation system. This CPU 315-2 PN/DP module provides robust processing power for medium-to-large scale industrial...

29 people are viewing this right now

Availability: Low stock: 8 left

SKU: 6ES7315-2EH13-0AB0
Vendor: Siemens
Category: PLC CPU Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Siemens 6ES7315-2EH13-0AB0 is a high-performance Central Processing Unit (CPU) designed for the SIMATIC S7-300 automation system. This CPU 315-2 PN/DP module provides robust processing power for medium-to-large scale industrial control applications. It features 256 KB of integrated working memory and supports dual-interface communication, allowing for seamless integration into complex network architectures. Please note that this specific model has been superseded by the 6ES7315-2EH14-0AB0.

Features

  • Integrated 256 KB working memory for program and data storage.
  • Dual interface capability: MPI/DP (up to 12 Mbit/s) and Ethernet PROFINET.
  • Requires a Micro Memory Card (MMC) for operation.
  • Supports advanced industrial communication protocols for distributed I/O and HMI connectivity.
  • Compact design suitable for standard S7-300 rail mounting.

Applications

This CPU is widely utilized in manufacturing, process automation, and infrastructure control systems where reliable PLC performance and PROFINET connectivity are required. It is ideal for managing distributed I/O stations, motion control tasks, and data exchange between plant-floor controllers and higher-level management systems.

Technical Specifications

Product Model 6ES7315-2EH13-0AB0
CPU Type CPU 315-2 PN/DP
Working Memory 256 KB
Rated Voltage 24 V DC (20.4 V to 28.8 V range)
Current Consumption 650 mA (rated), 100 mA (no-load)
Power Loss 3.5 W (typical)
Inrush Current 2.5 A (typical)
Communication Interfaces MPI/DP (12 Mbit/s), PROFINET
Hardware Version 01
Firmware Version V2.6
Programming Software STEP 7 V5.4 SP2 or higher

Installation Guidelines

  • Ensure the CPU is mounted on a standard 35mm DIN rail and secured properly within the S7-300 rack.
  • Always power down the system before inserting or removing the CPU or any communication modules to prevent electrical arcing or damage to the backplane.
  • Use shielded cables for PROFINET and PROFIBUS connections to minimize EMI interference in industrial environments.
  • Ensure the 24V DC power supply is protected by a minimum 2A external fuse.
  • Handle the module using ESD-safe practices to prevent damage to sensitive internal components.
  • Verify that the required Micro Memory Card is correctly inserted before attempting to power up the unit.

FAQ

Is this CPU still the current production model?

No, the 6ES7315-2EH13-0AB0 has been officially replaced by the 6ES7315-2EH14-0AB0. This unit is typically sourced as a spare or for maintenance of existing legacy installations.

What programming software is required for this module?

This CPU requires Siemens STEP 7 V5.4 SP2 or higher for configuration and programming.

Does this unit include a memory card?

No, a Micro Memory Card (MMC) is required for operation but is not typically included with the CPU module itself. Please ensure you have a compatible MMC available for your project.
