Siemens 6ES7321-1BH02-0AA0 SIMATIC S7-300 Digital Input Module

Siemens 6ES7321-1BH02-0AA0 SIMATIC S7-300 Digital Input Module

Description

The Siemens 6ES7321-1BH02-0AA0 is a 16-channel digital input module designed for the SIMATIC S7-300 automation system. This module serves as a standard interface for connecting external 24V DC digital signals—such...

15 people are viewing this right now

Availability: Low stock: 4 left

SKU: 6ES7321-1BH02-0AA0
Vendor: Siemens
Category: Digital Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Siemens 6ES7321-1BH02-0AA0 is a 16-channel digital input module designed for the SIMATIC S7-300 automation system. This module serves as a standard interface for connecting external 24V DC digital signals—such as limit switches, proximity sensors (BERO), and pushbuttons—to the PLC controller. It provides galvanic isolation between the process signals and the internal backplane bus, ensuring reliable data acquisition in industrial environments. This unit acts as a direct successor to the 6ES7321-1BH01-0AA0.

Features

  • 16 digital inputs, isolated in groups of 16.
  • Rated input voltage of 24V DC.
  • Compatible with standard switches and two/three/four-wire proximity switches.
  • Compact 40mm wide module design for space-efficient DIN-rail mounting.
  • Opto-isolated signal processing for enhanced noise immunity.
  • Integrated status LEDs for clear signal state indication.

Applications

  • Manufacturing Automation: Monitoring machine interlocks, conveyor status, and sensor feedback.
  • Automotive Industry: Signal processing for robotic cells and assembly line synchronization.
  • Food & Beverage: Packaging line monitoring, including bottle detection and fill-level sensing.
  • Process Control: Tracking valve positions, pump status, and safety-related limit switch feedback.

Technical Specifications

Model 6ES7321-1BH02-0AA0
Number of Inputs 16
Rated Voltage 24V DC
Permissible Range (DC) 20.4V to 28.8V
Power Loss (typ.) 3.5W
Isolation 500V DC tested
Current Consumption (Backplane) 10mA max
Front Connector 20-pole

Installation Guidelines

  • Mounting: The module is designed to snap onto a standard S7-300 DIN rail. Ensure the module is securely locked into place.
  • Bus Connection: Always install the U-connector (bus connector) on the back of the module before mounting to establish communication with the CPU or adjacent modules.
  • Wiring: A 20-pin front connector is required for field wiring. Note that the connector features a mechanical coding mechanism; once keyed to this module type, it will only fit compatible units.
  • Handling: Observe ESD precautions when handling the module. Ensure the system power is disconnected before inserting or removing the module from the rack.

FAQ

What is the function of the 6ES7321-1BH02-0AA0?

It is a digital input module (SM 321) for the Siemens S7-300 PLC, providing 16 isolated inputs for 24V DC signals.

What are the input voltage requirements?

The rated input voltage is 24V DC. The permissible range for signal "0" is -30 to +5 V, and for signal "1" is 13 to 30 V.

Does this module require a front connector?

Yes, a 20-pin front connector is required for wiring. This connector is sold separately.
