Siemens 6ES5135-3KA31 Simatic S5-135U 21-Slot PLC Subrack

Siemens 6ES5135-3KA31 Simatic S5-135U 21-Slot PLC Subrack

Description

The Siemens 6ES5135-3KA31 is a 21-slot subrack engineered as the primary chassis for the Simatic S5-135U programmable logic controller system. This robust mechanical frame provides the necessary backplane architecture for...

25 people are viewing this right now

Availability: Low stock: 1 left

SKU: 6ES5135-3KA31
Vendor: Siemens
Category: PLC Rack
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Siemens 6ES5135-3KA31 is a 21-slot subrack engineered as the primary chassis for the Simatic S5-135U programmable logic controller system. This robust mechanical frame provides the necessary backplane architecture for high-speed data communication and power distribution across complex, multi-processor automation configurations. Designed for demanding industrial environments such as rolling mills and petrochemical processing, this chassis ensures structural integrity and reliable electrical connectivity for legacy S5-135U installations.

Features

  • 21-slot capacity for high-density I/O and CPU module configurations.
  • Rugged aluminum frame designed to withstand industrial vibration and mechanical stress.
  • Integrated multi-layer backplane with gold-plated connector pins to ensure low-resistance signal paths and oxidation resistance.
  • Parallel bus architecture supporting multi-processor communication without data collisions.
  • Optimized for standard 19-inch rack mounting.
  • Shielded signal routing to maintain communication integrity in high-EMI environments.

Technical Specifications

Model 6ES5135-3KA31
Series Simatic S5-135U
Slots 21
Logic Bus Supply 5 VDC / 18 A
Auxiliary Supply 24 VDC
Operating Temperature 0 to 55 deg C
Storage Temperature -40 to 70 deg C
Mounting 19-inch Rack

Installation Guidelines

  • Ensure the subrack is securely mounted in a standard 19-inch industrial cabinet with adequate clearance for airflow.
  • Always disconnect all power sources from the rack before inserting or removing any CPU, I/O, or power supply modules to prevent electrical arcing or damage to the backplane pins.
  • Verify that the backplane connectors are free of dust and debris before module installation.
  • Ensure proper grounding of the chassis to the cabinet earth bus to mitigate electromagnetic interference.
  • Maintain ambient operating temperatures within the 0 to 55 deg C range to ensure long-term reliability of the backplane components.

FAQ

Is this chassis compatible with all S5-135U modules?

Yes, the 6ES5135-3KA31 is designed to house standard S5-135U modules. Please ensure your specific module configuration does not exceed the 18 A current limit of the 5 VDC bus.

Does this unit include a power supply?

No, this is the subrack chassis only. It requires a compatible Siemens S5-135U power supply module to be installed in the designated slot to provide the necessary system voltages.
