TK-OAV061 Honeywell 6-Channel Analog Output Module

TK-OAV061 Honeywell 6-Channel Analog Output Module

Product Description

The TK-OAV061 is a high-reliability 6-channel analog output module designed for Honeywell HC900 and Experion control platforms. It provides fully isolated voltage outputs to drive field devices such as VFDs, valve positioners, and electrical actuators. Each...

23 people are viewing this right now

Availability: Low stock: 99 left

SKU: TK-OAV061
Vendor: Honeywell
Category: Analog Output Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Product Description

The TK-OAV061 is a high-reliability 6-channel analog output module designed for Honeywell HC900 and Experion control platforms. It provides fully isolated voltage outputs to drive field devices such as VFDs, valve positioners, and electrical actuators. Each channel is independently isolated, preventing ground loops and protecting the controller from field-side electrical noise and transients.

Optimized for precision and speed, the module delivers stable 0–10 V signals with a 2 ms loop update time, ensuring responsive and smooth control in dynamic process loops. Its compact form factor, low power consumption, and industrial-grade durability make it suitable for 24/7 operation in sectors including water treatment, power generation, HVAC, and laboratory automation.

Technical Specifications

Parameter Description
Model Designation TK-OAV061
Device Type Isolated Analog Output (AO) Module
Channel Capacity 6 independent channels
Signal Output Range 0–10 VDC
Drive Capability 20 mA per channel
Measurement Accuracy ±0.1% FS
Digital-to-Analog Resolution 12-bit
Loop Update Time 2 ms
Physical Dimensions (L × W × H) 3.5 × 14.0 × 14.5 cm
Unit Weight 0.28 kg

Core Applications

  • VFD Speed Control
    Provides precise voltage reference signals for pumps, fans, and other motor-driven devices.

  • Damper and Valve Positioning
    Controls 0–10 V actuators in HVAC and process airflow systems.

  • Remote Setpoint Transmission
    Sends analog reference values to secondary controllers or local display units.

  • Laboratory Automation
    Drives precision power supplies and variable equipment in test or R&D environments.

Frequently Asked Questions

Q: Does the TK-OAV061 support 4–20 mA current outputs?
A: No. This module is designed specifically for 0–10 V voltage outputs. For current loop applications, use a module such as TK-HAO081.

Q: Is the isolation between channels or just to the logic side?
A: Each of the six outputs is fully isolated, protecting both the field signals from the internal logic and minimizing interference between channels.
