Schneider Electric TSXSAZ10 TSX Micro PLC AS-Interface Master Module

Schneider Electric TSXSAZ10 TSX Micro PLC AS-Interface Master Module

Description

The TSXSAZ10 is a specialized AS-Interface master module designed for integration with the Schneider Electric TSX Micro PLC series. This module serves as the primary communication gateway between the PLC...

17 people are viewing this right now

Availability: Low stock: 6 left

SKU: TSXSAZ10
Vendor: Schneider
Category: AS-Interface Master Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The TSXSAZ10 is a specialized AS-Interface master module designed for integration with the Schneider Electric TSX Micro PLC series. This module serves as the primary communication gateway between the PLC controller and up to 31 AS-Interface field devices, facilitating efficient, real-time data exchange in demanding industrial automation environments. By streamlining the connection of sensors and actuators, it reduces field wiring complexity and enhances overall system reliability.

Features

  • Dedicated AS-Interface master functionality for TSX Micro PLC systems.
  • Supports communication with up to 31 server devices on the AS-Interface network.
  • Integrated I/O configuration providing 4 discrete inputs and 4 discrete outputs.
  • Optimized for low-latency scanning to ensure rapid control logic execution.
  • Compact design for seamless mounting on the TSX Micro PLC backplane.

Applications

This module is suitable for various industrial applications requiring distributed I/O management, including chemical processing plants, large-scale manufacturing lines, and automated material handling systems where reliable, real-time signal integration is essential.

Technical Specifications

Model TSXSAZ10
Manufacturer Schneider Electric
Product Line TSX Micro PLC
Module Type AS-Interface Master Module
Communication Capacity Up to 31 server devices
Discrete Inputs 4
Discrete Outputs 4
Operating Temperature 0 to 60 deg C
Mounting TSX Micro PLC backplane

Installation Guidelines

  • Ensure the PLC power supply is disconnected before installing or removing the module from the backplane.
  • Verify that the module is securely seated in the designated slot to ensure proper electrical contact with the backplane bus.
  • Use shielded cabling for AS-Interface network connections to minimize susceptibility to electromagnetic interference (EMI).
  • Maintain adequate spacing within the control cabinet to allow for proper ventilation and heat dissipation, keeping the ambient temperature within the 0 to 60 deg C range.
  • Follow standard ESD (Electrostatic Discharge) handling procedures when touching the module circuitry.

FAQ

What is the primary function of the TSXSAZ10?
The TSXSAZ10 acts as an AS-Interface master module, allowing the TSX Micro PLC to communicate with and control up to 31 field devices over an AS-Interface network.

How many I/O points does this module provide?
The module features 4 discrete inputs and 4 discrete outputs for direct signal integration.
