Siemens 6FM1470-3BE20 Simatic S5 WF470 Visualization Module

Siemens 6FM1470-3BE20 Simatic S5 WF470 Visualization Module

Description

The Siemens 6FM1470-3BE20, part of the WF470 series, is an intelligent visualization module designed for integration within the Simatic S5 PLC architecture. This module serves as a dedicated processor for...

28 people are viewing this right now

Availability: Low stock: 2 left

SKU: 6FM1470-3BE20
Vendor: Siemens
Category: Visualization Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Siemens 6FM1470-3BE20, part of the WF470 series, is an intelligent visualization module designed for integration within the Simatic S5 PLC architecture. This module serves as a dedicated processor for human-machine interface (HMI) tasks, offloading graphical rendering and diagnostic text generation from the host CPU. By managing screen masks, font libraries, and real-time data mapping locally, it ensures consistent display performance and rapid diagnostic feedback for industrial control environments.

Features

  • Dedicated graphical processing for Simatic S5 rack systems.
  • Supports custom screen masks and variable trend mapping for operator oversight.
  • High-speed backplane communication for real-time data updates.
  • Direct interface support for industrial video terminals and control input devices.
  • Reduces host CPU load by handling complex visual data processing independently.

Applications

This module is engineered for legacy automation systems where local, high-speed visualization is critical. Typical deployments include chemical processing plants, automotive assembly lines, and power distribution substations where operators require immediate access to process variables and fault diagnostics.

Technical Specifications

Model 6FM1470-3BE20 (WF 470)
System Compatibility Simatic S5
Power Consumption 12 W (via backplane)
Operating Temperature 0 to 55 deg C
Module Type Visualization / Intelligent Processor

Installation Guidelines

  • Ensure the Simatic S5 rack is powered down before inserting or removing the module to prevent electrical damage.
  • Verify that the module is correctly seated in the designated backplane slot to ensure reliable communication with the CPU.
  • Use shielded cabling for all external monitor and keyboard connections to minimize electromagnetic interference (EMI).
  • Maintain adequate ventilation within the control cabinet to keep the ambient temperature within the specified 0 to 55 deg C range.
  • Handle with standard ESD precautions to protect internal circuitry during installation or maintenance.

FAQ

What is the primary function of the 6FM1470-3BE20?

It acts as an intelligent visualization processor that translates digital data from the S5 PLC into graphical displays and text, allowing for real-time monitoring and diagnostics on connected industrial terminals.

Is this module compatible with modern PLC systems?

No, this module is specifically designed for the legacy Simatic S5 architecture and is not compatible with modern S7 or TIA Portal-based systems.

How is the module powered?

The module draws its operating power directly from the Simatic S5 backplane bus, with a typical consumption of 12 W.
