Woodward 5466-257 Analog I/O Module

Woodward 5466-257 Analog I/O Module

Product Description

The 5466-257 is a high-precision analog I/O expansion module engineered by Woodward for use in MicroNet control platforms, including TMR and Simplex architectures. This module is designed for high-speed deterministic control...

26 people are viewing this right now

Availability: Low stock: 10 left

SKU: 5466-257
Vendor: Woodward
Category: Analog I/O Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Product Description

The 5466-257 is a high-precision analog I/O expansion module engineered by Woodward for use in MicroNet control platforms, including TMR and Simplex architectures. This module is designed for high-speed deterministic control of large prime movers such as steam and gas turbines.

The module provides a centralized interface for multiple analog process signals, converting field sensor data into digital control information with minimal latency. It is optimized for turbine control loops where precise fuel, actuator, and process regulation is required.

The 5466-257 is built for high-density control cabinets and supports multiple control loops from a single chassis slot. Integrated onboard diagnostics continuously monitor A/D and D/A conversion integrity as well as output driver health, helping prevent control drift that could lead to combustion inefficiency or mechanical stress in rotating machinery systems.

Technical Specifications

Item Specification
Part Number 5466-257
System Compatibility MicroNet Simplex, MicroNet Plus, MicroNet TMR
Input Channels 8–16 configurable (hardware dependent)
Resolution 16-bit A/D and D/A
Update Rate 5 ms or 10 ms MicroNet control cycle synchronized
Isolation 500 Vrms galvanic isolation
Power Consumption 5 W @ 24 Vdc
Operating Temperature -40°C to +70°C

Application Scenarios

The 5466-257 is widely deployed in:

  • Gas turbine fuel valve control systems

  • Servo actuator positioning loops

  • Lube oil pressure monitoring

  • Cooling water and auxiliary process control

Its rugged design allows installation in turbine control cabinets, offshore platform engine rooms, and other harsh industrial environments where vibration and thermal cycling are common.

Technical FAQ

Can the 5466-257 be used in TMR configurations?
Yes. The module is fully compatible with MicroNet TMR architectures, where three redundant control channels operate using voting logic to prevent single-point failures from causing turbine shutdowns.

Does this module support HART communication?
No. The 5466-257 is designed for high-speed analog signaling only. Applications requiring HART over 4–20 mA communication should use a dedicated HART-capable I/O module from the MicroNet ecosystem.
