Woodward 5501-467 Power Supply Board

Woodward 5501-467 Power Supply Board

Product Description

The 5501-467 is a high-capacity power supply module developed by Woodward, Inc. for MicroNet Plus and MicroNet Simplex control platforms. It converts high-voltage industrial AC/DC power into regulated low-voltage 5 VDC logic power for...

24 people are viewing this right now

Availability: Low stock: 99 left

SKU: 5501-467
Vendor: Woodward
Category: Power Supply Board
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Product Description

The 5501-467 is a high-capacity power supply module developed by Woodward, Inc. for MicroNet Plus and MicroNet Simplex control platforms. It converts high-voltage industrial AC/DC power into regulated low-voltage 5 VDC logic power for control processors and I/O modules.

This module is optimized for Simplex system architectures, providing stable power delivery for turbine control, engine control, and large mechanical drive systems. It features intelligent thermal management with automatic current derating and front-panel LED diagnostics for quick maintenance assessment.

The module is designed for harsh industrial environments and supports high-altitude operation up to 4,000 meters, making it suitable for remote power generation sites.

Technical Specifications

Parameter Specification
Model 5501-467
Function Control system power supply
Platform Compatibility MicroNet Plus / MicroNet Simplex (Simplex operation only)
AC Input Voltage 180 – 264 VAC (47 – 63 Hz)
DC Input Support High-voltage DC compatible
Holdup Time 7 ms at 225 VDC
Output Voltage 5 VDC logic rail
Output Current 32 A @ 55°C28 A @ 60°C22 A @ 65°C (thermal derating)
Wiring Standard 14 AWG (2.5 mm²), 60°C minimum rating
Acoustic Level < 70 dBA
Operating Altitude Up to 4,000 m
Diagnostics 4 LED status indicators
Weight 1.5kg

Application

  • Utility-scale power generation control systems

  • Gas and steam turbine control skids

  • Large mechanical drive automation systems

  • Remote or high-altitude power sites

FAQ

Can this be used in redundant power configurations?
No. This module is designed strictly for Simplex operation. Redundant systems require a dual-supply power architecture.

Why does output current decrease at higher temperatures?
Thermal derating protects internal components from overheating and extends module service life.

Does it support 110V AC input?
No. The module requires 180–264 VAC high-voltage input.
