Woodward 8235-650 ProAct PISC II Actuator Driver Module

Woodward 8235-650 ProAct PISC II Actuator Driver Module

Configured for butterfly valve actuation in engine control loops, the Woodward 8235-650 (PISC II ProAct Integrated Speed Control) provides direct physical/electrical execution. The actuator driver module precisely regulates air or...

15 people are viewing this right now

Availability: Low stock: 6 left

SKU: 8235-650
Vendor: Woodward
Category: ProAct PISC II Actuator Driver Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Configured for butterfly valve actuation in engine control loops, the Woodward 8235-650 (PISC II ProAct Integrated Speed Control) provides direct physical/electrical execution. The actuator driver module precisely regulates air or air-fuel mixture flow by converting control loop commands into high-torque shaft displacement. Operating across a nominal 18 to 32 VDC input supply, it maintains closed-loop position stability across gaseous and diesel-fueled engine applications.

Hardware Specifications

Parameter Specification
Model 8235-650
Brand Woodward
Series ProAct PISC II
Origin USA
Weight 1.2 kg
Dimensions DN 120 nominal piping size chassis
Operating Temp Flow medium max temperature 85 deg C
Power Consumption 18-32 VDC nominal (8-40 VDC transient up to 1 min)
Max Working Pressure 5.2 bar absolute
Center of Gravity Offset 5.4 inches from valve bore centerline
O-Ring Specification Parker 2-255 (flange grooves)

Actuator Loop Feedback Response & Speed Regulation

The Woodward 8235-650 incorporates internal position feedback sensing to optimize actuator loop feedback response. The integrated driver electronics continuously compare input setpoint commands against physical butterfly valve shaft angle, delivering immediate dynamic torque adjustments to overcome aerodynamic flow forces. This rapid dynamic response reduces leakage and maintains steady-state speed control under variable engine load profiles.

Frequently Asked Questions

Q: What input supply voltage parameters are tolerated by the Woodward 8235-650 driver module?

A: The module operates on a nominal supply voltage range of 18 to 32 VDC, with internal voltage suppression handling severe transients between 8 and 40 VDC for durations up to 1 minute.

Q: What are the physical process interface limits for the DN 120 valve assembly?

A: The housing and valve body are rated for a maximum working pressure of 5.2 bar absolute, accommodating flow media temperatures up to 85 deg C.

Q: Which sealing specification is required for flange groove installation?

A: Flange mating interfaces require standard Parker 2-255 specification O-rings to ensure a gas-tight seal at the process connection.

Field Installation Guidelines

  • Verify that process piping is fully depressurized and cleared of particulate debris prior to installing the DN 120 valve body.
  • Inspect Parker 2-255 O-rings for defects and seat them evenly in the flange grooves before torquing flange bolts.
  • Route 24 VDC power and control wiring using shielded twisted-pair cables, keeping them isolated from high-voltage spark ignition lines.
  • Terminate cable shielding at the control panel ground bus only to prevent common-mode noise on position command inputs.
  • Ensure mounting bolts are secured with full thread engagement, accounting for the 5.4-inch center of gravity offset from the valve bore centerline.
