Woodward BL1840024 Battery Charger Module

Woodward BL1840024 Battery Charger Module

The Woodward BL1840024, also cataloged as the BL1840024 Battery Charger and Power Supply Unit, operates as a dedicated hardware component for industrial battery maintenance and auxiliary DC voltage regulation within...

20 people are viewing this right now

Availability: Low stock: 10 left

SKU: BL1840024
Vendor: Woodward
Category: Battery Charger Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

The Woodward BL1840024, also cataloged as the BL1840024 Battery Charger and Power Supply Unit, operates as a dedicated hardware component for industrial battery maintenance and auxiliary DC voltage regulation within power generation platforms.

Hardware Specifications

Parameter Specification
Model BL1840024
Brand Woodward
Origin USA
Weight 1.43 kg
Dimensions 273.6 mm x 214.1 mm x 59.2 mm
Operating Temp -20 to +60 deg C
Power Consumption 3-phase 360-530 VAC input
Output Voltage Adjustable 24-27.5 VDC
Output Current 1.5 A
Input Frequency 50/60 Hz
Storage Temperature -40 to +85 deg C

Harmonic Distortion Suppression and Thermal Heat Sink Dissipation

The Woodward BL1840024 converts 3-phase 360-530 VAC power into a stabilized 24 to 27.5 VDC supply, integrating harmonic distortion suppression filtering to protect sensitive controller circuitry. Built with passive thermal heat sink dissipation profiles integrated directly into the chassis, the unit maintains a continuous 1.5 A charging output without thermal degradation across operating temperatures from -20 to +60 deg C. Its closed-loop regulation maintains precise float and boost charge voltages to optimize battery longevity in high-vibration industrial settings.

Frequently Asked Questions

Q: What input power source parameters are required for the Woodward BL1840024?

A: The unit operates on a 3-phase AC line voltage ranging from 360 to 530 VAC at 50/60 Hz.

Q: What are the output voltage adjustability and current limits of this charger?

A: The power supply delivers an adjustable DC output from 24 to 27.5 VDC with a maximum rated current of 1.5 A.

Q: What physical envelope dimensions and total weight apply to enclosure layout planning?

A: The chassis measures 273.6 mm x 214.1 mm x 59.2 mm and weighs 1.43 kg.

Field Installation Guidelines

  • Mount the charger vertically against a metal enclosure backplate to maximize convective air flow across the heat sink cooling fins.
  • Connect the 3-phase AC mains through a 3-pole circuit breaker, verifying proper phase sequence and terminal tightness.
  • Route output DC power lines using twisted pair cables to reduce EMI, maintaining short lead lengths to the target battery bank.
  • Ensure a dedicated earth ground cable is securely connected to the main ground stud on the chassis prior to applying AC input power.
