Yokogawa AAM11-S2 Current Voltage Input Module

Yokogawa AAM11-S2 Current Voltage Input Module

The Yokogawa AAM11-S2, also cataloged as the AAM11 Current Voltage Input Module, operates as a dedicated hardware component for multi-range signal acquisition within CENTUM process control platforms. This module provides...

15 people are viewing this right now

Availability: Low stock: 50 left

SKU: AAM11/S2
Vendor: Yokogawa
Category: Current Voltage Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

The Yokogawa AAM11-S2, also cataloged as the AAM11 Current Voltage Input Module, operates as a dedicated hardware component for multi-range signal acquisition within CENTUM process control platforms. This module provides direct electrical execution for monitoring analog process variables, facilitating the conversion of voltage or current inputs into digital values for system-wide control and alarming.

Hardware Specifications

Parameter Specification
Model AAM11-S2
Brand Yokogawa
Origin Japan
Weight 0.08 kg
Dimensions 16.5 cm x 6 cm x 1 cm
Operating Temp -10 deg C to +60 deg C
Power Consumption < 2 W
Input Type Current and Voltage signals
Resolution 12-bit analog-to-digital conversion

DCS Instrumentation and Signal Conversion

The AAM11-S2 architecture is designed to maintain signal linearity across varying input ranges, supporting standard industrial instrumentation interfaces. The unit employs channel-to-channel signal conditioning to ensure data integrity before transmission to the system backplane. Its compact form factor allows for high-density slot mounting within the control cabinet, facilitating efficient space utilization while maintaining the galvanic requirements necessary to suppress common-mode electrical noise inherent in long-run field wiring.

Frequently Asked Questions

Q: Does the AAM11-S2 module support hot-swapping under normal operating conditions?

A: No, module replacement should be performed while the base unit slot is de-energized to prevent electrical arcing and potential damage to the backplane communication pins.

Q: Can the input range be configured for different voltage levels via software?

A: Yes, the module supports selectable input ranges through internal hardware jumpers and system software configuration to accommodate various field instrument outputs.

Field Installation Guidelines

  • Ensure the module is inserted fully into the backplane connector to guarantee a stable electrical interface for signal and power transmission.
  • Verify that all field signal wiring is terminated to the corresponding terminal block before power-up to prevent floating inputs.
  • Maintain physical separation between input signal wires and high-voltage power conduits to minimize electromagnetic interference (EMI).
  • Use shielded, twisted-pair cabling for all analog inputs and terminate the shield to the cabinet earth bar to improve signal-to-noise ratio.
  • Inspect the module edge connector for debris or oxidation before installation to ensure reliable contact within the I/O rack.
