Yokogawa AED5D-00 Terminal Board

Yokogawa AED5D-00 Terminal Board

Configured for analog signal field termination in CENTUM VP platforms, the Yokogawa AED5D-00 (AED5D-00 Terminal Board) provides direct physical/electrical execution. This 16-channel component serves as the primary AED5D terminal board...

16 people are viewing this right now

Availability: In stock

SKU: AED5D-05
Vendor: Yokogawa
Category: Terminal Board
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Configured for analog signal field termination in CENTUM VP platforms, the Yokogawa AED5D-00 (AED5D-00 Terminal Board) provides direct physical/electrical execution. This 16-channel component serves as the primary AED5D terminal board utilized to execute signal distribution and transient voltage suppression across process control network platforms.

Hardware Specifications

Parameter Specification
Model AED5D-00
Brand Yokogawa
Origin Japan
Weight 1.5 kg
Dimensions 482.6 mm x 465.1 mm x 440 mm
Operating Temp Standard industrial ambient
Power Consumption Subject to loop load (Rated 4 A, 24 VDC)
Input Channels 16 channels
Insulation Resistance 100 MOhm at 500 VDC

DCS Process Control and Surge Protection

The AED5D-00 integrates a built-in surge absorber to mitigate the impact of transient voltage spikes on sensitive field instrumentation loops. The board facilitates termination via M4 screw connectors, ensuring mechanical stability for long-term field wiring. Designed for standard 19-inch rack mounting, the unit maintains signal integrity by providing a low-resistance path to the cabinet common, while meeting JEM1459 compliance for dimensional and electrical specifications. The connection to the control system is managed via the KS1 cable interface, ensuring deterministic signal path continuity.

Frequently Asked Questions

Q: Is the AED5D-00 compatible with hazardous area (Ex i) applications?

A: No. The AED5D-00 is specified for non-explosion-proof environments. Do not install this board in areas requiring intrinsic safety barriers without external protection.

Q: How should the surge absorber be verified after a localized power surge?

A: Following a significant surge event, inspect the surge absorber component for signs of thermal damage or discoloration. Measure the insulation resistance between the signal terminals and the chassis ground to confirm the board remains within the specified 100 MOhm limit.

Field Installation Guidelines

  • Mounting: Secure the board to the 19-inch rack rails using the provided mounting holes. Ensure the board is grounded to the cabinet frame to complete the path for the surge protection circuit.
  • Wiring: Use M4 ring or spade lugs for field wire termination. Tighten screws to the recommended torque to prevent contact resistance, which can introduce measurement errors in analog loops.
  • Cable Interface: Connect the KS1 interface cable firmly to the board header. Ensure the locking mechanisms are fully engaged to prevent accidental disconnection due to rack vibration.
  • Grounding: Verify that the terminal board chassis has a low-impedance connection to the cabinet grounding busbar to ensure the effectiveness of the integrated surge absorber.
