The AMM42 is a high-density analog input multiplexer module engineered for the CENTUM CS 3000 distributed control system platform by Yokogawa Electric Corporation. It functions as a signal aggregation interface,...
Availability: Low stock: 99 left
Reliable Worldwide Delivery
30-Day Money-Back Guarantee
Need more details? Read our fullShipping PolicyandRefund Policy.
The AMM42 is a high-density analog input multiplexer module engineered for the CENTUM CS 3000 distributed control system platform by Yokogawa Electric Corporation. It functions as a signal aggregation interface, consolidating multiple field analog inputs into a streamlined controller channel to optimize I/O nest utilization.
By multiplexing several process signals through a single interface, the AMM42 significantly reduces hardware footprint while maintaining the data integrity required for industrial process control. It incorporates robust signal conditioning and galvanic isolation to protect the system backplane from field-side electrical disturbances.
Designed for high-density installations, the module is particularly suitable for monitoring non-critical process variables where efficient integration is prioritized. The AMM42 supports hot-swapping, allowing maintenance or replacement without requiring a full DCS shutdown.
| Item | Specification |
|---|---|
| Manufacturer | Yokogawa Electric Corporation |
| Module Model | AMM42 |
| System Series | CENTUM CS 3000 / CS 1000 |
| Input Type | Multi-channel Analog Input (Multiplexed) |
| Signal Compatibility | 1–5 V DC or 4–20 mA (via external shunt resistor) |
| Isolation | Channel-to-system electrical isolation |
| Installation | Standard Yokogawa I/O nest compatible |
| Dimensions | 15.2 cm × 7.6 cm × 25.4 cm |
| Weight | 0.6 kg |
The AMM42 is widely deployed in:
Oil & gas production and refining facilities
Chemical processing plants
Thermal and combined-cycle power generation stations
It is particularly effective for clustered monitoring of auxiliary temperatures, tank levels, and pressure transmitters, helping reduce total rack count and cabinet space in large-scale control rooms.
How does the AMM42 handle current signals if it is voltage-based?
The module typically measures voltage inputs. For standard 4–20 mA process loops, a precision 250 Ω resistor is installed at the terminal board to convert the current signal into a 1–5 V DC voltage input.
Is the AMM42 compatible with the newer CENTUM VP series?
The AMM42 was primarily developed for the CENTUM CS 3000 platform. While certain legacy modules may be supported via migration or interface kits, compatibility with specific CENTUM VP revisions and I/O nests should be verified prior to integration.
