Yokogawa ASI533-S Analog Output Module

Yokogawa ASI533-S Analog Output Module

Configured for precise analog output signal execution in CENTUM VP and related Yokogawa DCS platforms, the Yokogawa ASI533-S (ASI533-S Analog Output Module) provides direct physical/electrical execution.

Suffix Breakdown & Model...

16 people are viewing this right now

Availability: Low stock: 50 left

SKU: ASI533-S
Vendor: Yokogawa
Category: Analog Output Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Configured for precise analog output signal execution in CENTUM VP and related Yokogawa DCS platforms, the Yokogawa ASI533-S (ASI533-S Analog Output Module) provides direct physical/electrical execution.

Suffix Breakdown & Model Matrix

  • ASI533: Base model designation for the 8-channel analog output hardware module.
  • -S: Standard hardware build revision suffix indicating standard industrial environmental grading.

Hardware Specifications

Parameter Specification
Model ASI533-S
Brand Yokogawa
Origin Japan
Weight 0.30 kg
Dimensions 282 mm x 210 mm x 20 mm
Operating Temp Standard industrial range (-20 to 70 deg C implied by drift specs)
Power Consumption 5 V DC: 150 mA; 24 V DC: 350 mA
Output Channels 8 channels (individually isolated)
Output Signal 4 to 20 mA DC (HART communication supported)
Load Resistance 0 to 750 ohm at 20 mA; 0 to 600 ohm at 23 mA
Response Time Step response time 100 ms; data update period 10 ms

4-20 mA HART Loop Protocol

The module executes precise 4-20 mA HART loop protocol communications across all eight channels, driving actuators and control valves with a maximum output current of 23 mA. Individual channel-to-channel and galvanic isolation of 1500 V AC protects internal control circuits from field-side ground loops and transient voltage spikes. Cold junction compensation and drift suppression circuitry maintain an accuracy of plus-minus 48 microamps under nominal operating conditions.

Frequently Asked Questions

Q: Does the ASI533-S module support hot-swapping during active CENTUM VP controller execution?

A: Yes, when installed within a redundant node and baseplate architecture supporting online maintenance, the module can be replaced without halting system operations.

Q: How is backplane power distributed across the internal rails during full load operation?

A: The module draws a maximum current of 150 mA from the 5 V DC system bus and 350 mA from the 24 V DC external supply rail.

Field Installation Guidelines

  • Mount the module securely onto the designated DIN rail or panel mounting fixture within the CENTUM VP node cabinet.
  • Connect field loop wiring to the terminal blocks, ensuring proper shielding and grounding to prevent electromagnetic interference.
  • Verify that ambient panel temperatures and thermal dissipation profiles comply with specified operating limits before system power-up.
