Yokogawa F3CU04-0S Temperature Control and PID Module

Yokogawa F3CU04-0S Temperature Control and PID Module

The Yokogawa F3CU04-0S (F3CU04-0S) is a versatile temperature control and PID processing module designed for the FA-M3 programmable controller platform. It facilitates sophisticated thermal management through four independent control loops,...

27 people are viewing this right now

Availability: In stock

SKU: F3CU04-0S
Vendor: Yokogawa
Category: Temperature Control and PID Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

The Yokogawa F3CU04-0S (F3CU04-0S) is a versatile temperature control and PID processing module designed for the FA-M3 programmable controller platform. It facilitates sophisticated thermal management through four independent control loops, supporting advanced regulatory functions including ramp/soak programming and automated PID tuning.

Hardware Specifications

Parameter Specification
Model F3CU04-0S
Brand Yokogawa
Origin Japan
Control Loops 4 (Independent)
Input Types Thermocouples, RTDs, Analog Inputs
Digital I/O 16 Digital Inputs, 8 Digital Relay Outputs
Analog I/O Up to 8 Inputs, Up to 4 Outputs
Sampling Period 250 ms per loop
Communication RS-485, Ethernet, USB
Power Supply 24 V DC
Operating Temp 0 to 55 deg C

Control Capabilities and Integration

The F3CU04-0S offers high-density processing, combining analog sensing with digital alarm and control functions in a single module. The inclusion of ramp/soak programming allows for complex thermal profiles, while the auto/manual tuning features optimize PID performance for dynamic industrial processes. With integrated communication interfaces including RS-485 and Ethernet, the module supports seamless data exchange with supervisory systems, enabling centralized monitoring and configuration of the four control loops.

Frequently Asked Questions

Q: Can this module perform ramp/soak thermal profiling?

A: Yes. The F3CU04-0S supports advanced ramp/soak programming, enabling the execution of complex temperature-time profiles essential for heat treatment and process manufacturing.

Q: How is the module powered?

A: The F3CU04-0S operates on a 24 V DC power supply, which is standard for most industrial control cabinet configurations.

Field Installation Guidelines

  1. Ensure the 24 V DC power source is stable and appropriately fused to protect the module circuitry.
  2. Utilize twisted-pair shielded cables for all thermocouple and RTD sensor inputs to mitigate electromagnetic noise in industrial environments.
  3. Configure the communication parameters (RS-485 or Ethernet) according to the host system requirements before initializing the control loops.
  4. Mount the module in a well-ventilated area within the FA-M3 cabinet, maintaining the specified operating temperature of 0 to 55 deg C to ensure component longevity.
  5. Perform a commissioning test of the digital relay outputs to verify alarm functionality and control interlocks before placing the system into active operation.
