Yokogawa NFDV151-P10/CCC01 Digital Input Module

Yokogawa NFDV151-P10/CCC01 Digital Input Module

Configured for high-density digital signal acquisition in STARDOM control networks, the Yokogawa NFDV151-P10/CCC01 (NFDV151-P10 Digital Input Module) provides direct electrical execution of 32-channel isolated logic status monitoring.

Hardware Specifications

19 people are viewing this right now

Availability: Low stock: 99 left

SKU: NFDV151-P10/CCC01
Vendor: Yokogawa
Category: Digital Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Configured for high-density digital signal acquisition in STARDOM control networks, the Yokogawa NFDV151-P10/CCC01 (NFDV151-P10 Digital Input Module) provides direct electrical execution of 32-channel isolated logic status monitoring.

Hardware Specifications

Parameter Specification
Model NFDV151-P10/CCC01
Brand Yokogawa
Origin Japan
Weight 0.3 kg
Dimensions Standard FCN/STARDOM module housing
Operating Temp 0 deg C to +40 deg C
Power Consumption 500 mA at 5 VDC
Input Channels 32 isolated (sink/source compatible)
Rated Input Voltage 24 VDC
Isolation Voltage 2 kV AC (input to system)
Input Response Time <= 8 ms

Process Control and Signal Isolation

The module utilizes galvanic isolation to provide 2 kV AC protection between input field signals and the internal system backplane. This architecture prevents common-mode noise and ground-loop currents from propagating into the FCN autonomous controller. Integrated surge protection is implemented on each of the 32 channels, providing voltage transient suppression for field instrumentation. The circuitry supports deterministic input detection with a max cycle of 25 Hz for pushbutton inputs, ensuring data consistency for time-sensitive logic execution.

Frequently Asked Questions (FAQ)

Q: Is this module capable of handling both sink and source input configurations?

A: Yes, the NFDV151-P10/CCC01 is engineered to support both sink and source input types, offering flexibility for different field device wiring standards without requiring hardware modifications.

Q: What is the insulation rating between the channel common groups?

A: The module provides an isolation voltage of 500 V AC between common segments, which are grouped every 16 channels to maintain segmentation integrity.

Field Installation Guidelines

  1. Ensure the control system is powered down before inserting the module into the FCN base unit slot.
  2. When utilizing pressure clamp terminal blocks, strip wires to exactly 11 mm to ensure proper contact and pull-out resistance.
  3. For cabling, adhere to the 0.5–2 mm² (AWG 20–14) range; exceeding this diameter may compromise the terminal block structural integrity.
  4. Verify that field wiring provides an OFF voltage level of <= 5.0 VDC to prevent false-high logic status reading.
  5. Ensure the cabinet environment remains within the 5% to 95% RH non-condensing humidity range to prevent internal moisture accumulation on the PCB surface.
